Laboratory Mixers

HLaboratory mixers direct drive to help provide high-speed mixing for lower viscosity and a gear reduction shaft to help boost torque for higher viscosity materials.
Availability:
Quantity:
  • Speed

Homogenizing mixers for Chemical Industry


Homogenizing mixers - devices intended for manufacture of cosmetic and pharmaceutical products: creams, ointments, pastes. The devices are made in compliance with the highest GMP (Good Manufacturing Practice) and GEP (Good Engineering Practice) standards.


Homogenization requires the ingredients to be processed until a uniform globule or particle size. For most products, including creams, ointments, sauces, flavoring emulsions and pharmaceutical suspensions, this requires a globule or droplet size in the range of 2 – 5 microns


This can be achieved using Mixer Homogenizer. The precision-machined  workhead generates exceptionally high shear rates in a three stage mixing/homogenizing process; The high speed rotor draws materials into the workhead where they are intensely mixed. Centrifugal force then drives the materials to the periphery of the workhead and subjects them to mechanical shear in the precision gap between the rotor and stator. This is followed by intense hydraulic shear, as the product is forced through the stator screen at high velocity and circulated back into the mix. Fresh material is continually drawn into the workhead, progressively reducing globule or particle size and quickly resulting in a homogeneous, uniform product.


According to an individual customer’s requirements, the devices may be equipped with such systems as: control and adjustment of heating-cooling control – measurement of pressure control – measurement of the substance level/weight Control – measurement of pH, oxygen, etc. The devices may be equipped with a dedicated control system with a program permitting high automation of the process to increase its efficiency and safety. Our mixers may be constructed in any configuration depending on the required capacity (30 – 4000 l) and working parameters
