The tilt camera adopts a one-piece structure. Through excellent shape structure design and advanced manufacturing technology, a more professional five-lens camera is created. It is equipped with a professional fixed-focus surveying and mapping lens as standard.
The total pixels are up to 120 million, and the housing is tilted forward by 8°. The fixed inclination angle makes the attitude data more accurate;
the body adopts industrial-grade metal composite material, which has the characteristics of high structural strength and strong protection ability.
The camera can work normally in an environment of -20 to 50 degrees Celsius, thanks to special manufacturing materials And excellent design structure, the camera has excellent performance in terms of anti-electromagnetic interference, heat resistance, cold resistance, waterproof, anti-fall, anti-ultraviolet, and dust-proof
the camera has dual working modes, tilt and ortho mode one-key switch, one machine for multiple purposes , Type-C dual interface data is quickly exported.
| Camera parameters | |
| Camera size | 140 X 140 X 89mm |
| Number of lenses | 5/pcs |
| Front focal length | 25mm |
| Tilt focal length | 35mm |
| Camera pixels | 120 million effective pixels |
| Lens angle | 48° |
| Sensor size | APS-C frame (23.5 X 15.6mm) |
| Pixel size | 3.91um |
| Image resolution | 6000 X 4000 |
| Exposure mode | timing / fixed distance exposure |
| Minimum exposure interval | ≥0.8s |
| Storage capacity | 640GB / 1280GB |
| Camera working mode | Ortho/Tilt |
| Photo feedback | Real-time feedback |
| Camera image transmission | Real-time monitoring image transmission |
| Electrical parameters | |
| Camera power supply | SkyPort integrated power supply |
| Data copy | Type-C dual interface transmission |
| Transmission speed | ≥80MB/S |
| Working environment | |
| Working temperature | -20℃--50℃ |
| Working humidity | 90% |
1. Double working mode, one-key switch between tilt and ortho mode;
2. Two-way data export, stable and fast;
3. Dual communication interfaces, multi-platform compatibility;
4. 5-channel real-time hot shoe feedback, real-time monitoring image transmission;
5. RTK microsecond time synchronization to obtain high-precision coordinates;
6. The camera firmware is automatically upgraded online to optimize the user experience;
7. Standard DP image processing studio software, intelligent management of flight sorties;
8. IP54 level protection;
9, 8° horizontal compensation,;
